Smart Flame Detection Camera
|
FLAME DETECTIOR |
|
Method |
Detection using 2 kinds of IR Sensors |
|
Distance / Angle |
30m / 100° (Fire : 1.5m / Sensitivity : 10) |
|
Sensitivity |
1 ~ 10 steps |
|
Detection Time |
3, 5, 10 sec |
|
Action Time |
Keep On, 20, 30, 40, 50, 60 sec |
|
Flame Alarm Out |
Event: Low / Normal: Hi-Z |
|
VIDEO |
|
Sensor Type |
1/2.8” 2.1 Megapixel SONY STARVIS CMOS Sensor |
|
Total Pixels |
1920(H) × 1080(V) = 2.1M pixels |
|
Scanning System |
Progressive Scan |
Min.
Illumination |
B/W |
0.0005Lux@50IRE, F1.3, 3100K, DSS(OFF), AGC(10) |
|
Color |
0.2Lux@50IRE, F1.3, 3100K, DSS(OFF), AGC(10) |
|
Lens |
Filter |
True Day & Night (ICR) |
|
Type |
2.7~12mm DC IRIS varifocal 2 Motor Lens (ICR) |
|
Video Output (SDI)
|
Output |
1 (BNC 1.0 Vp-p, 75Ω) |
|
Resolution |
1080p 30fps / 25fps |
|
Video Format |
HD-SDI / EX-SDI 1.0 / EX-SDI 2.0 Selectable |
|
Video Output (CVBS)
|
Output |
1 BNC |
|
Resolution |
720x480 30fps / 720x576 25fps |
|
Video Format |
Analog SD |
|
Camera Functions
|
Filter |
True Day & Night |
|
AGC |
0 ~ 10 steps |
|
Mirror |
Horizontal / Vertical |
|
WDR |
OFF, LOW, MIDDLE, HIGH |
|
BLC |
OFF, LOW, MIDDLE, HIGH |
|
ACE |
OFF, LOW, MIDDLE, HIGH |
|
DNR |
OFF, LOW, MIDDLE, HIGH |
|
DSS |
OFF, AUTO, x2 ~ x32 |
|
White Balance |
AUTO, AUTO EXT, PRESET, MANUAL |
|
Defog |
OFF, AUTO, MANUAL |
|
Electric Shutter |
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, FLICKER, MANUAL |
|
HLC |
0 ~ 20 steps |
|
Privacy |
OFF/ON (10 Zones) |
|
IR LED |
30 pcs (support SMART IR/IR strength) |
|
Control |
Control Method |
DVR (CoC/UCC-A), CMS(Control Center) |
|
ENVIRONMENTAL & PHYSICAL |
|
Power |
Input Voltage |
DC 48V(±10%) with Coax. |
|
Power Consumption |
IR OFF : 3W (max) / IR ON : 6W (max) |
|
Environments |
Operating Temp/Humidity |
-10°C ~ 50°C / 0%RH ~ 80%RH |
|
Certification |
KC |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
