SONY STARVIS Image Sensor
Highly sensitive SONY STARVIS CMOS Sensor provides crystal clear image in low light condition
|
SONY STARVIS CMOS Sensor |
General Sensor |
 |
 |
Higher performance SoC
High performance ISP functions such as 3DNR, WDR, and etc.
Revolutionary response speed and stabilized performance.
3D-DNR 3D-Digital Noise Reduction
Advanced 3D-DNR technology detects and eliminates unnecessary noise by conducting comprehensive analysis of image pixels.
WDR Wide Dynamic Range
Realize one clear image by combining overexposed and underexposed identical images in backlight condition.
ONVIF Profile-S
Support standard protocol version , ONVIF Profile-S, which makes it compatible with 3rd party’s software and system.
|
Flame Detector |
|
Detection Method
|
Detecting using IR Sensor (1 sensor) |
|
Detection Distance / Angle
|
30m / 100° (Fire : 1.5m / Sensitivity : 10)
|
| Sensitivity
| 1~10 steps |
| Detection Time
| 0.5, 1, 3, 5, 10 sec. |
| Action Time
| Keep On, 20, 30, 40, 50, 60 sec
|
| External Alarm In | - |
| Camera |
|---|
|
Image Sensor |
1/2.8”, 2.1Megapixel Sony STARVIS Sensor
|
|
Full Resolution |
1920(H) x 1080(V) = 2.1M pixels |
|
Scanning System |
Progressive Scan |
|
Min. Illumination |
Color : 0.2Lux@50IRE / F1.2 / 3100K / AGC:10
BW : 0.0005Lux@50IRE / F1.2 / 3100K / AGC:10
|
|
Lens |
Filter : True Day & Night (ICR)
Type : 3.6mm Fixed Mega Pixel Lens |
|
Day & Night |
AUTO / COLOR / BW / EXTERN |
|
WDR |
LOW / MIDDLE / HIGH |
|
BLC |
OFF / ON
|
|
HLC |
LEVEL(0~20) / COLOR |
|
AGC |
0~10 |
|
ACE |
OFF / LOW / MIDDLE / HIGH |
|
DNR |
OFF / LOW / MIDDLE / HIGH |
|
DSS |
OFF / AUTO / x2 / x4 / x8 / x16 / x32
|
|
SHARPNESS |
0~10 |
|
Mirror |
Horizontal / Vertical |
|
White Balance |
AUTO / AUTOext / PRESET / MANUAL |
|
Electric Shutter |
INDOOR / OUTDOOR / INDOOR-ANTI BLUR / OUTDOOR-ANTI BLUR / MANUAL(1/30~1/30000, 12steps) |
|
Privacy |
ON / OFF (BOX-10 Positions) |
|
DE-FOG |
OFF / ON (MODE / LEVEL) |
|
IR LED |
30 pcs |
|
Video |
|
Compression Type |
H.264 (MPEG4 AVC) Main profile, Baseline profile / MJPEG
|
|
Resolution |
1st : 1920×1080 / 1280×720 / 800×600 / 704×480 / 704×400 / 640×360 / 480×272 / 320×184
2nd : 640×360 / 480×272 / 320×184
3rd : 1920×1080
|
|
Bitrate |
128Kbps ~ 5Mbps |
|
Frame Rate |
30fps@1080p |
|
Streaming |
1st : H.264 Stream up to 1080p 30fps
2nd : H.264 nHD Stream / 30fps
3rd: JPEG 1080p Stream / 1fps
|
|
Network & Software |
|
Interface |
1 Fast Ethernet RJ-45 port (10/100Mbps) |
|
Network Type |
Fixed IP / DHCP |
|
DDNS |
Not Supported
|
|
Port |
HTTP : 80
RTSP : 554
|
|
Protocol |
HTTP / RTSP/RTP / Onvif / TCP/IP / UDP / ARP / ICMP / DHCP
|
|
Onvif |
Support |
|
Simultaneous Users |
Max. 3 users |
|
DST |
Support |
|
NTP |
Support |
|
IP Address Filtering |
TBD |
|
Web Browser (Recommended)
|
IE 11 |
|
Web Monitoring |
IE : ActiveX based / Other browser : JPEG based |
|
Web Configuration |
Multi-platform web config / Desktop (Mac / Linux / Windows) |
|
NVR |
NVRs supporting Onvif |
|
PC CMS Software |
Control Center Standard (bundle) / Control Center Pro |
|
Relay Server |
WinRDS |
|
Electrical & Environmental
|
|
Power Source |
DC 12V ± 10% / PoE (802.3af, 36V~57V)
|
|
Power Consumption |
IR OFF : 150mA / IR ON : 400mA (MAX)
|
|
Operating Temperature |
-10°C ~ 45°C |
|
Humidity |
0% RH ~ 80% RH |
|
Certification |
KC, FCC, CE |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
