VMS Control Center

  • Central Monitoring Software supporting Max. 1024 units
  • Consist of Monitoring, Playback, Setup Program and other Utilities
  • Max. 144ch multi-screen monitoring
  • Max. 2 monitors and 288 channels per PC
  • Support 4K monitor and 4K resolution
  • Support HW decoding (Live view, Playback)
  • Support RTSP streaming
  • Grouping Viewset(customized multi-screen) and eMAP layer(GIS map)
  • Search by Calendar, Time Line, Event, Text, Smart, Thumbnail and Instant
  • Emergency bell popup, People count, License plate search and etc.
  • Status&Action panel graphically displays the status of connected units
  • Alarm Log panel shows the logs of event and alarm
  • Schedule backup performs auto backup for selected period
  • Direct connect DVR’s HDD to PC for Playback/Search/Backup/Copy
  • Authority setup for each user
  • Remote DVR(remote DVR control), Service channel feature

* System Requirements
Recommended system requirements for running Control Center.

ItemsRecommended
CPU Intel® Core i7-14700 2.1GHz
Main Memory RAM 16GB or higher
GPU NVIDIA Geforce RTX 3050
Network 1000 Ethernet NIC or higher
OS Windows 11(x64)



Support FULL HD Video
This product supports normal image of SD CIF/HALF/D1 along with live monitoring and playback/backup for high quality picture of UHD 2160p(3840x2160),
QHD 1440p(2560x1440), HD 1080p(1920x1080), 720p(1280x720), nHD(640x360). Also it supports live monitoring on the camera supporting RTSP protocol.

　- Support 4K (UHD) and 4M (QHD) with 30fps in live real-time monitoring
　- Support up to 25ch at 1080p with 30fps each channel in live real-time monitoring
　- Support up to 64ch at nHD with 30fps each channel in live real-time monitoring



Live Monitoring
Support various monitoring screen and high quality image display without delay for each channel.

　- 2 Monitors connection support
　- Supports various screen split for monitoring “1/4/6/7/8/9/10/13/16/25/36/49/64/81/100/121/144”
　- Full Screen Mode
　- Can add the image to the desired position by drag-and-drop operation with mouse
　- Function for management of group viewset
　- Layered map function
　- Auto Sequential switcher, Event Pop-up
　- Real-time audio output
　- Support Mic



Playback
Support convenient function for search and playback.

　- Support 64 split screen playback simultaneously
　- Full Screen Mode
　- Search by Calendar/time line/text/smart/thumbnail/bookmark
　- Playback by time, date, channel
　- Playback by event image separately
　- Support various speed playback (Max. 64x)
　- Support watermark check
　- Support image adjustment by channel
　- Digital Zoom In/Out
　- Playback/Search/Backup by direct connect DVR’s HDD to PC



Recording and Back-up
Support the function to store the image recording or real-time video monitoring, schedule and real-time backup unit’s recorded data.

　- Support Quick Recording and Image saving of monitoring’s video
　- Real-time backup of unit’s recorded image
　- Auto backup via schedule backup
　- Event log record/search/backup



Others
　- Support manufacturer’s all IP Camera, SD DVR, HD DVR, NVR, WinDVrS, WinRDS
　- Interfacable to Thermal detection camera, Flame detection camera.
　- Supports interface with TLS unit.
　- Support Remote DVR
　- RTSP streaming support
　- Max. 1024 units can be connected
　- Support user rights, user operating limitation and user log-in
　- Support saving of unit’s setting information
　- Import/Export setting information
