Key Feature/Demo Video
Heat Detection Sensor
Heat detection up to 450℃. Maximize thermal transmittance and sensor sensitivity by applying thermal sensor with special glass.
Detecting object’s temperature and high-definition live monitoring at the same time.
Camera sends push alarm to DVR(NVR) and PC(CMS) when it detects abnormal temperature.
Applicable on heat sensitive devices & facilities and unmanned factories in a diverse industry.
SONY STARVIS Image Sensor
Highly sensitive SONY STARVIS CMOS Sensor provides crystal clear image in low light condition.
SONY STARVIS CMOS Sensor |
General Sensor |
 |
 |
UTC(CoC)
Camera control over coax cable.
Control camera’s OSD or zoom/focus remotely (DVR, PC) without additional cable construction.
Made in Korea
Different league from low priced Chinese products.
Proven quality of Made in Korea and reasonable price.
Sensor Type |
2.1 Megapixel SONY STARVIS CMOS
Sensor |
Total Pixels
|
1920 (H) × 1080 (V) = 2.1M pixels |
Scanning System |
Progressive Scan |
Thermal |
Sensor |
LWIR Sensor, wavelength 8~14 um |
FOV / Distance |
51° (HFOV), 39° (VFOV) / 1~5m, More than 6m |
Detection Degree |
50°C ~ 450°C |
Emissivity |
MATT(0.96), SEMI_MATT(0.80)
SEMI_GLY(0.60), GLOSSY(0.3), MANUAL(0.1 ~ 0.99) |
Minimum Object Size |
Distance 1m : 0.05m (H) x 0.05m (V)
Distance 10m : 0.5m (H) x 0.5m (V) |
Detection Time |
1, 3, 5, 10 sec. |
Action Time |
Keep On, 20, 30, 40, 50, 60 sec |
Alarm Output |
OFF / ON (Active Low, Active High) |
Lens |
Filter |
True Day & Night (ICR) |
Type |
3.6mm FIXED MEGA LENS (ICR)
|
Video |
Output |
1 (BNC 1.0 Vp-p, 75Ω) |
Resolution |
1080p 30fps / 25fps
|
Format |
HD-SDI / EX-SDI / EX-SDI 2.0
|
Video Control |
AGC |
LEVEL 0~10 |
S/N Ratio |
More than 52dB |
Back Light Compensation |
OFF / HLC / BLC / WDR |
ACE |
OFF / LOW / MIDDLE / HIGH |
Min. Illumination |
0.02Lux (DSS X32) |
DNR |
OFF / LOW / MIDDLE / HIGH |
Iris Adjust. |
DC / Manual |
White Balance |
AUTO / AUTOext / PRESET / MANUAL
|
Electric Shutter |
INDOOR / OUTDOOR / INDOOR-ANTI-BLUR /
OUTDOOR-ANTI-BLUR / FLICKER / MANUAL (11 Steps)
|
OSD Language |
ENG |
Day&Night |
COLOR / BW / EXTERN / AUTO |
Defog |
OFF / ON (AUTO, MANUAL-LOW / MIDDLE / HIGH) |
Privacy |
OFF / ON (Programmable 16 zones) |
Defect |
LIVE DPC |
DSS |
OFF / AUTO / X2~X32 |
Digital Effect |
OFF / H-MIRROR / V-MIRROR |
IR LED |
30 pcs |
Smart IR |
OFF / ON |
Input Voltage |
DC 12V(±10%, Adapter) |
Power Consumption |
IR OFF : 3W (MAX) / IR ON : 5W (MAX) |
Operation Temp./Humidity |
-10℃ ~ +50℃ / MAX 90% RH |
Storage Temp./Humidity |
-20℃ ~ +60℃ / MAX 90% RH |
Certification |
KC |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
