Video input format |
BNC |
HD-SDI, EX-SDI(1.0 / 2.0 / 2.1), EX-SDI TDM |
IP(Ethernet) |
WESP, Onvif Profile S |
Resolution / Frame Rate |
HD-SDI
EX-SDI 1.0
EX-SDI 2.0
EX-SDI 2.1 |
1920×1080@30fps,1920×1080@25fps
2560×1440@30fps,2560×1440@25fps |
EX-SDI TDM |
1920×1080@30fps, 1920×1080@25fps |
IP |
1st stream: 1280×720~2560×1440
2nd stream: max 1280×720 |
Connectors |
4ch, 75Ω BNC connector |
PoC |
4ch, Power over Coax, Max. 22W/ch |
CoC |
4ch, Control over Coax |
VIDEO OUTPUT |
Video output |
HDMI/VGA Duplicate Mode |
1, 4 split-screen
HDMI : 1920×1080
VGA : 1920×1080
User defined display / Alarm pop-up / Sequential switching
|
VGA Spot Mode |
Not Supported |
RECORDING |
Compression |
H.264 / JPEG |
Resolution |
Same as input resolution (1920×1080, 2560×1440) |
Rate |
Max. 120fps@1920×1080,2560x1440 |
Quality |
10 levels up to 8Mbps@2M, 12Mbps@4M |
Mode |
Normal/Event, Schedule/Event, Emergency |
Schedule |
24hrs / 7days |
PLAYBACK |
Mode |
Instant Playback / Search |
Speed |
Max. 120fps@1920×1080,2560x1440 |
Search type |
Date/Time, Calendar/Time-line, Event, Thumbnail(Interval/Motion), Text, Bookmark |
Block playback |
24hours ~ 99days |
EVENT & ALARM |
Event source |
Motion detection, Video Loss, Text input, System |
Event check schedule |
24hrs / 7days |
Event action |
Buzzer, E-mail, FTP, Video pop-up, Camera Preset, Mobile Alarm Push, System alarm |
MD area |
15×10 |
Text input |
POS/ATM support, AVE VSI Pro/Hydra support |
SYSTEM ALARM |
Event source |
HDD fail. HDD almost full, Password fail, WRS/DDNS fail, Recording Fail |
Event action |
Pop-up Message, Buzzer, E-mail, Mobile Alarm Push |
AUDIO |
Input/output |
HDMI output |
Compression |
G.711 |
Direction |
Both |
PTZ |
Protocols |
Support various protocols including C1080(D1080), C1080PT-Z20, Pelco-D, Pelco-P, Samsung, Panasonic and others |
NETWORK |
Interface |
1 Gigabit Ethernet (10/100/1000Mbps) |
Type |
Static IP, Dynamic IP, xDSL |
DDNS |
WNS, DynDNS, NoIP, WRS |
Bandwidth limit |
0.01 ~ 100Mbps, unlimited |
NTP |
Server / Client / Both |
Users |
10 Monitoring, 4 Playback, 1 Configuration |
RTSP |
Supported |
UPnP |
UPnP auto port forwarding |
Streaming |
H.264 stream, High resolution
1 additional H.264 stream, Normal resolution
1 JPEG stream, normal resolution for e-mail or mobile |
Service streaming |
Service Channel or Remote DVR |
SECURITY |
User level |
1 admin, 10 users |
User privilege |
Menu, PTZ, Playback, Power off, Copy, Network MIC, Camera setup |
IP filtering |
Supported |
STORAGE & BACKUP |
Storage devices |
1 internal SATA HDDs, Gigabit network for NS04R/UHS04R |
RAID Level |
External storage including NS04R/UHS04R (Level 1/5/10) |
File system |
High-performance proprietary file system
Data-loss protection against power interrupt
Safe HDD head parking in power failure |
Capacity |
10TB HDD Supported
Max. 256TB with cascaded NS04R/UHS04R |
Backup type |
Multi-channel exe file, Single channel avi file, JPEG(Capture) |
Backup device |
2 USB 2.0 drive (2 front) |
FAT32(Max 32GB), NTFS |
S.M.A.R.T. |
Health checking and alarm, Reallocation sector monitoring and alarm |
SERIAL & I/O |
Serial port |
1 RS-485 |
Sensor input |
Sensor of IP camera |
CONTROLLER |
Device |
Mouse, IR remote controller (option), Joystick Keyboard (option) |
SOFTWARE |
HTML5 Webviewer |
Monitoring / Event / PTZ / Playback for browser supporting HTML5 |
WebViewer |
Monitoring / Event / PTZ / Playback for IE |
Mobile viewer |
Monitoring / Playback / Alarm Push / PTZ / Audio / Log View with iPhone & Android |
CMS |
Control Center, Max. 1024 units |
SDK |
ActiveX(COM) SDK |
ENVIRONMENTAL & PHYSICAL |
Dimension |
260(W) × 241(D) × 45(H) mm |
Weight |
1.2 Kg (No HDD) |
Operating temperature |
5°C~45°C (41°F ~ 113°F) |
Operating humidity |
80% below, free of condensation |
Power |
DC 48V/2.5A |
IPFR |
Supporting IPFR (Intelligent Power Failure Recovery) |
Power consumption |
Max. 20W, Typical 15W (No HDD) |
Approval |
KC, FCC, CE, RoHS |
