| Camera Module |
|---|
| Image Sensor |
1/2.7″ progressive scan CMOS |
| Mini. Illumination |
Color：0.01Lux @ (F1.65，AGC ON)
B/W：0.002Lux @ (F1.65，AGC ON)
0 Lux with IR |
| Image setting |
Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client software / browser |
| Shutter Speed |
50Hz: 1/25s ~1/25,000s; 60Hz: 1/30s ~ 1/30,000s |
| White Balance |
Auto / Manual / Indoor / Outdoor |
| Gain |
Auto / Manual |
| Day & Night |
IR Cut filter |
| 3D DNR |
Auto / Manual |
| Image Enhancement |
BLC, HLC, WDR |
| Privacy Mask |
4 areas, up to 8 per request |
| Defog |
Electronic |
| EIS |
YES |
| Regional Exposure |
NO |
| Picture overlay |
Logo picture could be overlaid on video with 128×128pixels, 24bits jpg format |
| Lens |
|---|
| Focus length |
f=4.8-120mm lens, 25x optical |
| Zoom Speed |
Approx. 3.6s (optical zoom, wide-tele) |
| Field of View |
Horizontal: 55°~2.4°±5%(wide-tele)
Vertical: 33°~1.4°±5%(wide-tele)
Diagonal: 61.5°~2.8±5%°(wide-tele) |
| Working distance |
wide: 1.0m ~ INF; tele: 1.5m ~ INF |
| Aperture Range |
F1.65 ~ F3.8 (wide-tele) |
| PTZ |
|---|
| Pan Range |
360°endless |
| Pan speed |
Configurable, from 0.1~200°/s, Preset speed: 240°/s |
| Tilt Range |
From -10° to 90° |
| Tilt Speed |
Configurable, from 0.1~200°/s, Preset speed: 240°/s |
| Proportional Zoom |
Yes |
| Preset |
360 |
| Cruise |
8 cruises, up to 16 presets for each cruises |
| Track |
4 tracks, record time over 3 minutes for each track |
| Power off memory |
Support |
| Action mode |
Preset / Cruise / Track / Auto Scan / Random Scan |
| 3D Positioning |
Support |
| PTZ Position Display |
Support |
| Schedule Task |
Preset / Cruise / Track / Auto Scan / Random Scan / Dome reboot |
| IR |
|---|
| IR Distance |
160m, dual stack IR LED Array |
| Smart IR |
Yes |
| Network |
|---|
| Max Resolution |
2560×1440 |
| Main stream |
25/30fps (2560x1440, 2304x1296, 1920x1080, 1280x720) |
| Sub stream |
25fps (1280x720, 704x576, 352x288)
30fps (1280x720, 704x480, 352x240) |
| Third Stream |
25fps (704x576, 480x240, 352x288)
30fps (704x480, 480x240, 352x240) |
| SVC |
Yes |
| Video compression |
Smart H.265 / H.264 / MJPEG |
| Audio compression |
G.711 A / U |
| Audio Enhancement |
NO |
| Protocols |
HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,DHCP, PPPoE |
| Simultaneous live view
|
Up to 6 channels |
| User / Host |
Up to 16 users, 3 levels: Administrator, Advanced User and Normal User |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address)
HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering |
| Smart Features |
|---|
| Basic event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, SD full, SD error) |
| Face recognize |
Default off, Detecting max 15 faces at same scene. Detecting, tracking, capturing |
| Road traffic |
Vehicle detecting and tracking |
| People Density |
Not support by this product |
| Smart Detection |
Tripwire, Bi
directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection, etc. More VCA per request
|
| Smart Tracking |
Smart tracking of human or vehicle, auto/manual |
| System Integration |
|---|
| Alarm Interface |
1 Alarm input(Dry contact); 1 Alarm output |
| Audio Interface |
1 audio input(MIC in); 1 audio output, line level, impedance,600Ω |
| Alarm Linkage |
Alarm actions, such as Preset, Cruise, Track, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card, Send Email, etc. |
| Network Interface |
1 RJ45 10M/100M Adaptive Ethernet ,Support PoE |
| CVBS |
None |
| RS 485 |
None |
| Storage |
One MicroSD slot, up to 256G |
| API |
ONVIF |
| Web Browser |
IE 8-11 |
| General |
|---|
| Power |
DC12V 25%,3000mA , PoE + (802.3.at), max 23W include IR ON+PTZ working |
| Working condition |
-40°C ~ 60°C (-40°F ~ 140°F), Cold start at – 30°C(30minutes waiting); 90%RH |
| Storage condition |
-40°C ~ 70°C; ≤ 95% RH |
| Protection |
6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Material |
Aluminum Alloy ; Plastic +Glass Fiber 15% |
| Dimensions |
Φ 173mm × 268mm ( 6.8′ Φ × 10.55′) |
| Weight |
Approx. 2.1 Kg (4.63 lb.) |
| Certification |
KC, CE, FCC |
