| Camera Module |
|---|
| Image Sensor |
1/2.8″ progressive scan CMOS |
| Mini. Illumination |
Color：0.00125Lux @ (F1.65，AGC ON)
B/W：0.00025Lux @ (F1.65，AGC ON)
0 Lux with IR |
| Image setting |
Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC and AWB adjusted by client software/browser
|
| Shutter Speed |
50Hz: 1/25s ~1/25,000s; 60Hz: 1/30s ~ 1/30,000s |
| White Balance |
Auto / Manual / Indoor / Outdoor |
| Gain |
Auto / Manual |
| Day & Night |
IR Cut filter |
| Privacy Mask
|
4 areas, up to 8 per request |
| 3D DNR |
Auto / Manual |
| Image Enhancement |
BLC, HLC, WDR |
| Defog |
Electronic |
| EIS |
YES |
| Regional Exposure |
NO |
| Picture overlay |
Logo picture could be overlaid on video with 128×128pixels, 24bits jpg format |
| Lens |
|---|
| Focus length |
f=4.8-120mm lens, 25x optical |
| Zoom Speed |
Approx. 3.6s (optical zoom, wide-tele) |
| Field of View |
Horizontal: 55°~±2.4°(wide-tele)
Vertical: 33°~±1.4°(wide-tele)
Diagonal: 61.5°~±2.8°(wide-tele) |
| Working distance |
wide: 1.0m ~ INF; tele: 1.5m ~ INF |
| Aperture Range |
Max F1.6 |
| PTZ |
|---|
| Pan Range |
360°endless |
| Pan speed |
Configurable, from 0.4~200°/s, Preset speed: 240°/s
Max Preset speed: 80°/s
|
| Tilt Range |
From -10°~90° |
| Tilt Speed |
Configurable, from 0.4°~200°/s, Preset speed: 240°/s
|
| Proportional Zoom |
Yes |
| Preset |
360 |
| Cruise |
8 cruises, up to 16 presets for each cruises |
| Track |
4 tracks, record time over 3 minutes for each track |
| Power off memory |
Support |
| Action mode |
Preset / Cruise / Track / Auto Scan / Random Scan |
| 3D Positioning |
Support |
| PTZ Position Display |
Support |
| Schedule Task |
Preset / Cruise / Track / Random Scan / Boundary Scanning / Dome reboot / Water Remover / Defrost |
| IR |
|---|
| IR Distance |
300m |
| Smart IR |
Yes |
| Network |
|---|
| Max Resolution |
1920×1080 |
| Main stream |
25/30fps (1920x1080, 1280x960, 1280x720) |
| Sub stream |
25fps (704x576, 640x480, 352x288)
30fps (704x480, 640x480, 352x240) |
| Third Stream |
25fps (1920x1080, 1280x960, 1280x720, 704x576, 640x480, 352x288)
30fps (1920x1080, 1280x960, 1280x720, 704x480, 640x480, 352x240) |
| SVC |
Yes |
| Video compression |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Audio compression |
G.711 A / U |
| Audio Enhancement |
NO |
| Protocols |
HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE, P2P |
| Simultaneous live view
|
Up to 10 (max 1920x1080 / 2Mbps) |
| User / Host |
Up to 16 users, 3 levels: Administrator, Advanced User and Normal User |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address)
HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering |
| Smart Features |
|---|
| Basic event |
Motion detection, Video tampering alarm, Exception(Network disconnected, IP address conflict, SD full, SD error) |
| Face recognize |
Default off (Per customer request), max 17 faces per scene, detect, capture, upload, score, compare
|
| Road traffic |
ehicle detecting and tracking |
| People Density |
Not support by this product |
| Smart Detection |
Tripwire, Bi-directional tripwire, Intrusion detection, Region entrance detection, Region exiting detection, etc. More VCA per request
|
| Smart Tracking |
Smart tracking of human or vehicle, auto/manual |
| System Integration |
|---|
| Alarm Interface |
1 Alarm input(Dry contact); 1 Alarm output
|
| Audio Interface |
1 audio input, line level,2.0-2.4Vpp, impedance 1KΩ ;1 audio output, line level, impedance,600Ω |
| Alarm Linkage |
Alarm actions, such as Preset, Cruise, Track, Memory Card Video Record, Trigger Recording, Upload to FTP/Memory Card, Send Email, etc |
| Network Interface |
1 RJ45 10M/100M Adaptive Ethernet, Support PoE
|
| CVBS |
None
|
| RS 485 |
None
|
| Storage |
One MicroSD slot, up to 256G
|
| API |
ONVIF |
| Web Browser |
IE8-11 with plug-in; Edge, Chrome, Firefox with plugin free |
| General |
|---|
| Power |
DC12V±25%,3000mA ,PoE (802.3.at, class 3), max 22W include IR ON+PTZ working |
| Working condition |
-40°C ~ 65°C (-44°F ~ 149°F), IR OFF; -40°C ~ 50°C(-40°F ~113°F ), IR ON; Cold start at - 30°C (0.5-1 hour waiting); 90%RH |
| Storage condition |
-40°C ~ 70°C ; ≤ 95% RH |
| Protection |
6000V Lightning Protection, Surge Protection and Voltage Transient Protection
|
| Material |
Aluminum Alloy(ADC12); Polymer(PC+GF15%) |
| Dimensions |
Φ 173mm × 268mm ( 6.8′ Φ × 10.55′) |
| Weight |
Approx. 2.1 Kg (4.63 lb.) |
| Certification |
KC, CE, FCC |
