VIDEO |
Sensor Type |
1/3” 2.1Megapixel CMOS |
Total Pixels |
1920(H) x 1080(V) = 2.1M pixels |
Scanning System |
Progressive Scan |
Min
Illumination |
B/W |
0.0005Lux@50IRE, F1.6, 3100K, DSS(OFF), AGC(10) |
Color |
0.2Lux@50IRE, F1.6, 3100K, DSS(OFF), AGC(10) |
Lens |
Mount |
D-Mount |
Filter |
True Day & Night (ICR) |
Type |
DC Iris, 2.8~11mm, F1.6, IRCorrective Megapixel Lens |
Video Output |
Output |
1 (BNC 1.0 Vp-p, 75Ω) |
Resolution |
1080p 30/25fps, 720p 30/25fps |
Video Format |
HD-SDI (SMPTE 292M compatible) or EX-SDI Selectable |
Distance |
HD-SDI: Max. 200m(600ft) video transmission through 5C-HFBT cable
EX-SDI: Max. 500m(1,500ft) video transmission through 5C-HFBT cable
|
Video Control |
Control Method |
OSD Menu, DVR (Supporting remote control via CoC), CMS(Control Center) |
AGC |
1 ~ 10 steps |
Mirror |
Horizontal / Vertical |
WDR |
OFF, 1 ~ 5 steps |
BLC |
OFF, LOW, MIDDLE, HIGH |
ACE |
OFF, ON |
DNR |
OFF, LOW, MIDDLE, HIGH |
DSS |
OFF, Auto, x2 ~ x10steps |
White Balance |
AUTO, PRESET, MANUAL |
Electric Shutter |
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR_ANTI BLUR, MANUAL(12 steps) |
D-ZOOM |
0 ~ 16 steps |
ANTI-FLICKER |
OFF, ON |
Lens Shading |
OFF, ON |
HLC |
0 ~ 10 steps |
DE-FOG |
OFF, ON(Auto / Manual) |
Privacy |
OFF, ON (15 Zones ) |
CONTROLINTERFACE |
Control |
RS485 |
ELECTRICITY |
Power Consumption |
DC 12V ±10%, 3W / AC 24V ±10%, 4W |
MECHANICAL |
Dimension |
D1080D : 130(ø) x 102.5(H)mm / D1080VD : 136.6(ø) x 106.5(H)mm |
Weight |
C1080D : 360g / C1080VD : 760g |
ENVIRONMENTS |
Operation Temp. / Humidity |
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH |
CERTIFICATIONS |
Certifications |
KC, FCC, CE, RoHS |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
