EX-SDI
By incorporating VLC (Visually Lossless Codec) into the existing HD-SDI transmission method, the transmission distance is extended without any loss in image quality.
Using a single coaxial cable (5C-HFBT), EX-SDI 1.0 supports Full-HD video transmission up to 500m, while EX-SDI 2.0 extends the range to 700m.
3D-DNR 3D-Digital Noise Reduction
Advanced 3D-DNR technology detects and eliminates unnecessary noise by conducting comprehensive analysis of image pixels.
WDR Wide Dynamic Range
Realize one clear image by combining overexposed and underexposed identical images in backlight condition.
Made in Korea
Different league from low priced Chinese products.
Proven quality of Made in Korea and reasonable price.
Description | NTSC | PAL |
Sensor Type |
2.1 Megapixel SONY STARVIS CMOS Sensor
|
Output Pixels
|
1920 (H) × 1080 (V) = 2.1M pixels
|
Scanning System |
Progressive Scan |
Lens |
Filter |
True Day & Night (ICR) |
Type |
2.8~12mm DC IRIS VARIFOCAL LENS (ICR)
|
Video |
Output |
1 BNC 1.0 Vp-p
|
Resolution |
1080p30 |
1080p25 |
Format |
HD-SDI / EX-SDI 1.0 / EX-SDI 2.0 selectable
|
Video Control |
AGC |
LEVEL 0~10 |
S/N Ratio |
More than 52dB |
BLC |
OFF / HLC / BLC / WDR |
ACE |
OFF / LOW / MIDDLE / HIGH |
Min. Illumination |
Color: 0.02Lux@F1.3 BW: 0.0005Lux@F1.3
|
DNR |
OFF / LOW / MIDDLE / HIGH |
Iris Adjustment |
DC / Manual
|
White Balance |
AUTO / AUTOext / PRESET / MANUAL
|
Electric Shutter |
INDOOR / OUTDOOR / INDOOR-ANTI-BLUR /
OUTDOOR-ANTI-BLUR / FLICKER / MANUAL (11 Steps)
|
OSD Language |
ENG |
Day&Night |
COLOR / BW / EXTERN / AUTO |
Defog |
OFF / ON (AUTO, MANUAL-LOW / MIDDLE / HIGH) |
Privacy |
OFF / ON (Programmable 10 zones) |
Defect |
LIVE DPC
|
DSS |
OFF / AUTO / X2~X32 |
Digital Effect |
OFF / H-MIRROR / V-MIRROR |
IR LED |
18 pcs (range: about 45m)
|
Smart IR |
OFF / ON |
Input Voltage |
DC 12V(±10%)
|
Power Consumption |
IR OFF : 64mA (MAX) / IR ON : 272mA (MAX)
|
Operation Temp./Humidity |
-10℃ ~ +50℃ / MAX 90% RH |
Storage Temp./Humidity |
-20℃ ~ +60℃ / MAX 90% RH |
Certification |
FCC, CE |
(rev 1.9.7)
제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
