Description | NTSC | PAL | |
Sensor Type | 2.1 Megapixel SONY STARVIS CMOS Sensor | ||
Output Pixels | 1920 (H) × 1080 (V) = 2.1M pixels | ||
Scanning System | ON / OFF (normal CCTV mode) | ||
Lens | Filter | True Day & Night (ICR) | |
Type | 5~50mm DC IRIS VARIFOCAL LENS (ICR) | ||
Video | Output | 1 (BNC 1.0 Vp-p, 75Ω) | |
Resolution | 1080p30 | 1080p25 | |
Format | HD-SDI / EX-SDI 1.0 / EX-SDI 2.0 selectable | ||
Video Control | AGC | LEVEL 0~10 | |
S/N Ratio | More than 52dB | ||
BLC | OFF / HLC / BLC / WDR | ||
ACE | OFF / LOW / MIDDLE / HIGH | ||
Min. Illumination |
Color: 0.02Lux@F1.3 BW: 0Lux (IR LED On) |
||
DNR | OFF / LOW / MIDDLE / HIGH | ||
Iris Adjustment | DC / Manual | ||
White Balance |
AUTO / AUTOext / PRESET / MANUAL
|
||
Electric Shutter |
INDOOR / OUTDOOR / INDOOR-ANTI-BLUR /
OUTDOOR-ANTI-BLUR / FLICKER / MANUAL (11 Steps)
|
||
OSD Language | ENG | ||
Day&Night | COLOR / BW / EXTERN / AUTO | ||
Defog | OFF / ON (AUTO, MANUAL-LOW / MIDDLE / HIGH) | ||
Privacy | OFF / ON (Programmable 10 zones) | ||
Defect | LIVE DPC | ||
DSS | OFF / AUTO / X2~X32 | ||
Digital Effect | OFF / H-MIRROR / V-MIRROR | ||
IR LED |
Super IR 12 pcs (recommend 10~15m, hori/vert < 40 degree) |
||
Smart IR | OFF / ON | ||
OSD Control | OSD key | ||
Input Voltage | DC 12V(±10%) | ||
Power Consumption | IR OFF : 180mA (MAX) / IR ON : 1500mA (MAX) | ||
Operation Temp./Humidity | -10℃ ~ +50℃ / MAX 90% RH | ||
Storage Temp./Humidity | -20℃ ~ +60℃ / MAX 90% RH | ||
Certification | KC |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
