VIDEO INPUT |
|
Video input |
Channel |
8CH IP video input |
|
Protocol |
WESP, Onvif Profile S |
|
Format |
H.265 / H.264 |
|
Resolution |
1st stream: 704×576~3840×2160
2nd stream: 352×240~1280×720
|
|
Performance |
80Mbps |
|
Stream |
RTSP over TCP, RTSP over HTTP |
|
PoE |
8 PoE ports (Max 15.4W/port, Total 59W) |
|
PoE Mode |
802.3af / midspan |
|
VIDEO OUTPUT |
|
Video output |
Port |
1HDMI, 1VGA |
|
Format |
HDMI : 4K/1080p
VGA : 1920×1080, 1280×1024, 1024×768 |
|
Modes |
Duplicate : HDMI, VGA main
|
|
Display |
Main: 1, 4, 6, 9 split-screen |
|
RECORDING |
|
Compression |
H.264 / H.265 |
|
Resolution |
1st stream: 704×576~3840×2160
2nd stream: Max D1
|
|
Rate |
Total 240 fps, Max 30fps/ch @ 4K |
|
Bitrate |
1st stream : Max. 8Mbps
2nd stream : Max. 2Mbps
|
|
Mode |
Manual&Event / Schedule&Event / Emergency |
|
Schedule |
24hrs / 7days |
|
PLAYBACK |
|
Mode |
Instant Playback / Search |
|
Speed |
1/16x, 1/8x, 1/4x, 1/2x, 1x, 2x, 4x, 8x, 16x, 32x, 64x |
|
Search type |
Time/Calender, Event, Thumbnail(Time, Motion), Text |
|
Block playback |
1day ~ 365days |
|
EVENT & ALARM |
|
Event source |
Motion detection, Sensor input, Video Loss, Text input, AI, System |
|
Event check schedule |
24hrs / 7days |
|
Event action |
Relay, Buzzer, Video pop-up, Camera Preset, System alarm |
|
Text input |
POS/ATM support, AVE VSI Pro/Hydra support |
|
SYSTEM ALARM |
|
Event source |
HDD fail. HDD almost full, Password fail, WRS/DDNS fail,
Recording Fail
|
|
Event action |
Pop-up Message, Buzzer, Relay |
|
AUDIO |
|
Input/output |
Not Supported |
|
Compression |
Not Supported |
|
Direction |
Not Supported |
|
PTZ |
|
Protocols |
IP Camera with Onvif protocol & WESP protocol |
|
NETWORK |
|
Interface |
1 Gigabit Ethernet RJ-45 port (10/100/1000Mbps) |
|
Protocol |
WESP, HTTP, RTSP/RTP, (Onvif), UPnP, TCP/IP, UDP, ARP, ICMP, DHCP, SMTP, SNMP, SNTP, TLS
|
|
DDNS |
Not Supported |
|
Tx Bandwidth limit |
1~78Mbps |
|
NTP |
Mode : Server / Clinet / Both
Server : Public / Private
|
|
Users |
Total 10 Users (Monitor + Playback), Playback 3 Users |
|
TLS |
Supported |
|
Service Streaming
|
Not supported |
|
SECURITY |
|
User level |
1 admin, 10 users |
|
User privilege |
Menu, PTZ, Playback, Power on/off, Copy, Network MIC, Camera Setup |
|
IP filtering |
10 IP address ranges |
|
Certified |
TTA |
|
STORAGE & BACKUP |
|
Storage devices |
1 SATA HDD |
|
RAID Level |
Not supported
|
|
File system |
High-performance proprietary file system
Data-loss protection against power interrupt
|
|
Capacity |
20TB HDD Supported per SATA Port
|
|
Backup type |
Multi-channel exe file, JPEG(Capture)
|
|
Backup device |
2 USB 2.0 drive (1 front, 1 rear)
FAT32(Max 32GB), NTFS |
|
S.M.A.R.T. |
Health checking and alarm, Reallocation sector monitoring and alarm |
|
SERIAL & I/O |
|
Serial port |
1 RS-485 |
|
Sensor input |
8 Dry-contacts + sensor of IP camera |
|
Relay output |
1 Relay |
|
CONTROLLER |
|
Device |
Joystick Keyboard(option), Mouse, IR remote controller(option) |
|
SOFTWARE |
|
HTML5 Webviewer
|
Not Supported |
|
ActiveX Webviewer |
Not Supported |
|
Smart Phone App. |
Monitoring / Playback / PTZ / Audio / Log View with iPhone & Android |
|
CMS |
Control Center, Max. 1024 Units |
|
SDK |
ActiveX(COM) SDK |
|
ENVIRONMENTAL & PHYSICAL |
|
Dimension |
300(W) × 208.7(D) × 49(H) mm |
|
Weight |
1.1kg (No HDD) |
|
Operating temperature |
0°C ~ 40°C (32°F ~ 104°F) |
|
Operating humidity |
90% below, free of condensation |
|
Power |
DC48V 1.5A, 50/60Hz
|
|
IPFR |
Not supported |
|
Power consumption |
Max 5W without HDD (TBD) |
|
Approval |
KC, FCC, CE, TTA |
|
TTA Verified |
|
펌웨어 파일명 |
ndvr_uhn808ph1v3tta_10.8.104.dat |
|
버전 정보 |
10.8.104 |
|
펌웨어 해시 값(SHA-256) |
563F97D757D72EDB38E69AE2C5040418308C9DF1ADBC62B19BE24E4533025205 |
