FLAME DETECTION |
|
Flame Detector |
Detection Method |
Detection using a dedicated IR Sensors |
|
Detection Distance & Angle |
30m / 80° |
|
Sensitivity |
Adjustable within 10 Steps |
|
Detection Time |
3, 5, 10 sec |
|
Action Time |
Keep On, 20, 30, 40, 50, 60 sec |
|
Alarm Notification |
Alarm message on video, Alarm signal transmission through Coax Cable, Digital output |
|
VIDEO |
|
Video Sensor |
1/3”, 2.1Megapixel CMOS |
|
Sensor Pixels |
1920(H) x 1080(V) = 2.1M pixels |
|
Scanning System |
Progressive Scan |
Min
Illumination |
B/W |
0.0005Lux@50IRE, F1.6, 3100K, DSS(OFF), AGC(10) |
|
Color |
0.2Lux@50IRE, F1.6, 3100K, DSS(OFF), AGC(10) |
|
Lens |
Filter |
True Day & Night (ICR) |
|
Type, Focal Length |
3.6mm Fixed Megapixel Lens |
|
Video Output |
Output |
1 BNC, 1.0 Vp-p, 75Ω |
|
Resolution |
1080p 30/25fps, 720p 30/25fps |
|
Video Format |
HD-SDI (SMPTE 292M compatible) or EX-SDI Selectable |
|
Transmission Distance |
HD-SDI : Max. 200m(650ft) video transmission through 5C-HFBT cable
EX-SDI : Max. 400m(1,200ft) video transmission through 5C-HFBT cable
|
|
Video Control |
Control Method |
OSD menu, DVR, CMS (Control Center) |
|
AGC |
0 ~ 10 steps |
|
Mirror |
Horizontal / Vertical |
|
WDR |
OFF, LOW, MIDDLE, HIGH |
|
BLC |
OFF, LOW, MIDDLE, HIGH |
|
ACE |
OFF, LOW, MIDDLE, HIGH |
|
DNR |
OFF, LOW, MIDDLE, HIGH |
|
DSS |
OFF, Auto, x2 ~ x32steps |
|
White Balance |
AUTO, AUTOext, PRESET, MANUAL |
|
Electric Shutter |
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL |
|
D-ZOOM |
x1 ~ x16 steps |
|
Lens Shading |
OFF, ON |
|
HLC |
0 ~ 20 steps |
|
DE-FOG |
OFF, ON(Auto / Manual) |
|
Privacy Masking |
OFF, ON (18 Zones ) |
|
CONTROL INTERFACE |
|
Control |
RS-485, Wired remote controller, DVR & CMS |
|
ELECTRICITY |
|
Power Consumption |
DC12V±10%, 700mA |
|
MECHANICAL |
|
Dimension |
Refer to the dimension |
|
Weight |
Approx. 450g |
|
ENVIRONMENTS |
|
Operation Temp. / Humidity |
-10 ºC ~ 50 ºC / 0%RH ~ 80%RH |
|
CERTIFICATIONS |
|
Certifications |
CE/ FCC/ MSIP(KC) |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
