VIDEO INPUT | ||
---|---|---|
Video input format | BNC |
HD-TVI 1080p/720p
HD-A 1080p
Analog 960H/SD
|
IP | Onvif Profile S | |
Resolution / Frame Rate | HD-TVI |
1920×1080 / 25, 30fps 1280×720 / 25, 30fps |
HD-A | 1920×1080 / 25, 30fps | |
Analog 960H | 960×480 / 60i or 960×576 / 50i | |
Analog SD | 720×480 / 60i or 720×576 / 50i | |
IP | 1920×1080 / 2048×1536 | |
Connectors | 16ch, 75Ω BNC connector | |
CoC | 16ch, Control over Coax | |
VIDEO OUTPUT | ||
Video output |
HDMI/VGA
Duplicate Mode
|
1, 4, 6, 9, 10, 13, 16 split-screen
HDMI : 3840×2160, 1920×1080
VGA : 1920×1080, 1280×1024, 1024×768, 800×600
User defined display / Alarm pop-up / Sequential switching
with Analog Spot
|
VGA Spot Mode |
1, 4, 9, 16 split-screen
1920×1080, 1280×1024, 1024×768
User defined display / Sequential switching
without Analog Spot
|
|
Analog Spot |
1, 4, 9, 16 split-screen
CVBS
User defined display / Sequential switching
|
|
RECORDING | ||
Compression | H.264 / JPEG | |
Resolution | 1920×1080, 1280×720, 960×480(576) | |
Rate | Max. 480/400 fps | |
Quality | 10 levels up to 8Mbps | |
Mode | Normal/Event Record, Schedule/Event Record, Emergency Record | |
Schedule | 24hrs / 7days | |
PLAYBACK | ||
Mode | Instant Playback / Search | |
Speed | Max. 480/400fps | |
Search type | Date/Time, Calendar/Time-line, Event, Thumbnail(Interval/Motion), Bookmark | |
Block playback | 24hours ~ 99days | |
EVENT & ALARM | ||
Event source | MD(Motion Detection), Sensor, Video Loss | |
Event check schedule | 24hrs / 7days | |
Event action |
Buzzer, Relay, E-mail, FTP, Alarm pop-up
Mobile Alarm Push |
|
MD area | 15×10 | |
SYSTEM ALARM | ||
Alarm source | HDD fail, HDD almost full, Password fail, WRS fail | |
Alarm action | Warning message, Buzzer, E-mail, Mobile Alarm Push | |
AUDIO | ||
Input/output | 4 RCA input / HDMI & 1 RCA output | |
Compression | G.711 | |
Direction | Both | |
PTZ | ||
Protocols |
41 models including C1080, C1080PT-Z20B, C1080PT-Z10B, Pelco-D, Pelco-P, Samsung, Panasonic and others
|
|
NETWORK | ||
Interface | 1 Ethernet port (10/100Mbps) | |
Type | Static IP, Dynamic IP, xDSL, UPnP, RTSP | |
DDNS | WNS, DynDNS, NoIP, WRS | |
Bandwidth limit | Supported | |
NTP | Server / Client / Both | |
Users | 10 Monitoring, 4 Playback | |
Streaming |
H.264 stream, High resolution
1 additional H.264 stream, Normal resolution
1 JPEG stream, Normal resolution for e-mail or mobile
|
|
SECURITY | ||
User level | 1 admin, 10 users | |
User privilege | Playback, Menu, Copy, PTZ, Camera Setup, Relay, Power, Network Mic | |
IP filtering | Supported | |
STORAGE & BACKUP | ||
Storage devices | 2 internal SATA HDDs | |
File system |
High-performance proprietary file system
Data-loss protection against power interrupt |
|
Backup type |
EXE : multi channel with log
AVI : signle channel
JPEG : single channel capture
|
|
Backup device | USB 2.0 drive (2 ports) | |
S.M.A.R.T. | Temperature and Health checking | |
SERIAL & I/O | ||
Serial port | 1 RS-485 | |
Sensor input | 4 Dry-contacts | |
Relay output | 1 Relays | |
CONTROLLER | ||
Device | IR remote controller, Joystick Keyboard, Mouse | |
SOFTWARE | ||
HTML5 Web viewer
|
Monitoring / Event / PTZ / Playback for browser supporting HTML5 | |
WebViewer | Monitoring / Event / PTZ / Playback for IE | |
Java viewer | Monitoring / Event / PTZ for IE, Chrome, Safari | |
Mobile App |
Monitoring / Playback / Alarm Push / PTZ / Audio / Log View with iPhone & Android
|
|
CMS | Control Center, Max. 1024 units | |
SDK | ActiveX(COM) SDK | |
ENVIRONMENTAL & PHYSICAL | ||
Dimension | 380(W) x 267.8(D) x 45(H) mm | |
Weight | 1.66kg (No HDD) | |
Operating temperature | 5°C~45°C (41°F ~ 113°F) | |
Power |
DC 12V / 4A (option : DC 12V / 5A) - 소비전력이 6W 이상인 고용량 HDD를 사용할 경우 12V 5A (option) 어댑터를 사용하시기 바랍니다. HDD의 소비전력은 HDD의 스펙을 참조하시기 바랍니다. (It is highly recommended to use an DC 12V 5A adapter (option) to use a high capacity HDD with a power consumption of 6W or more. Please refer the HDD's specification for power consumption of HDD.) |
|
Power consumption | Max. 15W (without HDD) | |
Approval | FCC, KC, CE, RoHS |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
