4K UHD 초고화질로 더 선명하고 생생하게
초고화질의 4K UHD 해상도로 더 넓은 영역의 감시와 원거리 이미지의 확대도 자유롭고 깨끗하게!
Full-HD 보다 2배 더 선명한 4M QHD, 4배 더 선명한 4K UHD 해상도의 영상까지 저장 가능한 DVR
UNIVERSAL 현존하는 모든 비디오 포맷 지원 (WDC4216F-U 모델은 TDM 지원 제외)
IP Camera는 물론 SD부터 4K UHD까지, 모든 비디오 포맷을 지원하는 유니버셜 DVR
어떤 현장이든, 어떤 카메라든 고민없이 유니버셜 DVR 하나면 OK!
전용 VMS 무료 지원
최대 1024대의 DVR 연결, 다양하고 막강한 기능으로 효율적인 원격 모니터링이 가능한 전용 VMS(Control Center) 무료 제공
VIDEO INPUT | ||
---|---|---|
Video input format | BNC |
HD-SDI, EX-SDI(1.0 / 2.0 / 2.1) AHD, TVI, CVBS(960H, SD) |
IP(Ethernet) | WESP, Onvif Profile S | |
H.264 | ||
Resolution / Frame Rate |
HD-SDI EX-SDI 1.0 EX-SDI 2.0 EX-SDI 2.1 |
1920×1080@30fps, 1920×1080@25fps 2560×1440@30fps, 2560×1440@25fps 3840×2160@30fps, 3840×2160@25fps |
AHD |
1920×1080@30fps, 1920×1080@25fps 2560×1440@30fps, 2560×1440@25fps |
|
TVI | 1920×1080@30fps, 1920×1080@25fps | |
CVBS(960H) |
960×480@60i, 720×480@60i 960×576@50i, 720×576@50i |
|
IP |
1st stream: 1280×720~3840×2160 2nd stream: max 1280×720 |
|
Connectors | 16ch, 75Ω BNC connector | |
CoC | Control over Coax@AHD(2M, 4M), TVI(2M) | |
VIDEO OUTPUT | ||
Video output | Resolution |
HDMI : 3840×2160, 1920×1080 VGA : 1920×1080, 1280×1024, 1024×768, 800×600 BNC(SDI) : 1920×1080 BNC(CVBS) : 720×480, 720×576 |
Mode |
HDMI/VGA Main + CVBS Spot HDMI/SDI Main + CVBS Spot HDMI Main + VGA Spot + CVBS Spot HDMI Main + SDI Spot + CVBS Spot |
|
BNC(CVBS) | 1, 4, 9, 16 split-screen, Switching | |
BNC(SDI) |
Main : Same as HDMI output Spot : 1, 4, 9, 16 split-screen, Switching Format : HD-SDI, EX-SDI, EX-SDI 2.0 |
|
RECORDING | ||
Compression | H.264 / JPEG | |
Resolution | 3840×2160, 2560×1440, 1920×1080, 1280×720, 960×480 | |
Rate | Max. 480fps@1920×1080, Max. 240fps@2560×1440, Max. 120fps@3840×2160 | |
Quality | 10 levels up to 8Mbps@2M, 12Mbps@4M, 16Mbps@8M(4K) | |
Mode | Normal/Event Record, Schedule/Event Record, Emergency Record | |
Schedule | 24hrs / 7days | |
PLAYBACK | ||
Mode | Instant Playback / Search | |
Speed |
Max. 480fps@1920×1080 Max. 240fps@2560×1440 Max. 120fps@3840×2160 |
|
Search type | Date/Time, Calendar/Time-line, Event, Thumbnail(Interval/Motion), Text, Bookmark | |
Block playback | 1day ~ 365days | |
EVENT & ALARM | ||
Event source | Motion detection, Sensor input, Video Loss, Text input, AI, System | |
Event check schedule | 24hrs / 7days | |
Event action | Relay, Buzzer, E-mail, FTP, Video pop-up, Camera Preset, Mobile Alarm Push, System alarm | |
MD area | 15×10 | |
Text input | POS/ATM support, AVE VSI Pro/Hydra support | |
SYSTEM ALARM | ||
Event source | HDD fail. HDD almost full, Password fail, WRS/DDNS fail, Recording Fail | |
Event action | Pop-up Message, Buzzer, E-mail, Relay, Mobile Alarm Push | |
AUDIO | ||
Input/output | 4 RCA input / HDMI & RCA output | |
Compression | G.711 | |
Direction | Both | |
PTZ | ||
Protocols | HIK-C, AHD, C1080(D1080), C1080PT-Z20, Pelco-D, Pelco-P, Samsung, Panasonic and others | |
NETWORK | ||
Interface | 1 Gigabit Ethernet (10/100/1000Mbps) | |
Type | Static IP, Dynamic IP, xDSL | |
DDNS | WNS, DynDNS, NoIP, WRS | |
Bandwidth limit | 0.01 ~ 100Mbps, unlimited | |
NTP | Server / Client / Both | |
Users | 10 Monitoring, 4 Playback | |
RTSP | Supported | |
UPnP | UPnP auto port forwarding | |
Streaming |
H.264 stream, High resolution 1 additional H.264 stream, Normal resolution 1 JPEG stream, Normal resolution |
|
Service streaming | Service Channel or Remote DVR | |
SECURITY | ||
User level | 1 admin, 10 users | |
User privilege | Menu, PTZ, Relay, Playback, Power off, Copy, Network MIC, Camera setup | |
IP filtering | Supported | |
STORAGE & BACKUP | ||
Storage devices | 6 internal SATA HDDs, 1 external eSATA Interface, Gigabit network for NS04R/UHS04R | |
RAID Level | External storage including NS04R/UHS04R (Level 1/5/10) | |
File system |
High-performance proprietary file system Data-loss protection against power interrupt Safe HDD head parking in power failure |
|
Capacity |
Max. 128TB with eSATA, Max. 256TB with cascaded NS04R/UHS04R 12TB HDD Supported per SATA Port |
|
Backup type | Multi-channel exe file, Single channel avi file, JPEG(Capture) | |
Backup device |
3 USB 2.0 drive (2 front, 1 rear) FAT32(Max 32GB), NTFS |
|
S.M.A.R.T. | Health checking and alarm, Reallocation sector monitoring and alarm | |
SERIAL & I/O | ||
Serial port | 2 RS-485 | |
Sensor input | 16 Dry-contacts + Sensor of IP Camera | |
Relay output | 2 Relays | |
CONTROLLER | ||
Device | IR remote controller, Joystick Keyboard(option), Mouse | |
SOFTWARE | ||
HTML5 Webviewer | Monitoring / Event / PTZ / Playback for browser supporting HTML5 | |
WebViewer | Monitoring / Event / PTZ / Playback for IE | |
Mobile viewer | Monitoring / Playback / Alarm Push / PTZ / Audio / Log View with iPhone & Android | |
CMS | Control Center, Max. 1024 units | |
SDK | ActiveX(COM) SDK | |
ENVIRONMENTAL & PHYSICAL | ||
Dimension | 445×418×88 mm | |
Weight | 6 Kg (No HDD) | |
Operating temperature | 5°C~45°C (41°F ~ 113°F) | |
Operating humidity | 80% below, free of condensation | |
Power | AC free volt (100~240VAC), 50/60Hz | |
IPFR | Supporting IPFR (Intelligent Power Failure Recovery) | |
Power consumption | Max. 33W, Typical 26W(No HDD) | |
Approval | KC, FCC, CE |
( * 표시: 지원 예정 / * Marks: Scheduled to be supported)
제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
