Video input format |
BNC |
HD-SDI, EX-SDI, EX-SDI 2.0
AHD 2.0, Analog 960H/SD |
|
IP(Ethernet) |
IP Camera(Onvif) |
|
Resolution / Frame Rate |
HD-SDI
EX-SDI
EX-SDI 2.0 |
1920×1080@30fps
1280×720@30fps / 1280×720@60fps |
|
AHD 2.0 |
1920×1080@30fps |
|
Analog 960H |
960×480@60i |
|
Analog SD |
720×480@60i |
|
Connectors |
16ch, 75Ω BNC connector |
|
VIDEO OUTPUT |
|
Video output |
HDMI
VGA |
1, 4, 9, 10, 13, 16 split-screen
HDMI : 1920×1080
VGA : 1920×1080, 1280×1024, 1024×768, 800×600
User defined display / Alarm pop-up / Sequential switching |
|
BNC |
1, 4, 9, 10, 13, 16 split-screen
CVBS
User defined display / Sequential switching |
|
RECORDING |
|
Compression |
H.264 / JPEG |
|
Resolution |
1920×1080, 1280×720, 960×480 |
|
Rate |
Max. 480fps |
|
Quality |
10 levels up to 8Mbps |
|
Mode |
Normal/Event Record, Schedule/Event, Emergency Record |
|
Schedule |
24hrs / 7days |
|
PLAYBACK |
|
Mode |
Instant Playback / Search |
|
Speed |
Max. 480fps |
|
Search type |
Date/Time, Calendar/Time-line, Event, Thumbnail(Interval/Motion), Text, Bookmark |
|
Block playback |
24hours ~ 99days |
|
EVENT & ALARM |
|
Event source |
MD(Motion Detection), Sensor, Text, Video Loss |
|
Event check schedule |
24hrs / 7days |
|
Event action |
Relay, Buzzer, E-mail, FTP, Video pop-up, Camera Preset, Mobile Alarm Push |
|
MD area |
15×10 |
|
Text input |
POS/ATM support, AVE VSI Pro/Hydra support |
|
SYSTEM ALARM |
|
Alarm source |
HDD fail, HDD almost full, Password fail, WRS fail, Fan Fail |
|
Alarm action |
Warning message, Buzzer, E-mail, Relay, Mobile Alarm Push |
|
AUDIO |
|
Input/output |
4 RCA input / HDMI & RCA output |
|
Compression |
ADPCM (32Kbps, 16KHz, 16bit sampling) |
|
Direction |
Both |
|
PTZ |
|
Protocols |
41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Pelco-P, Samsung, Panasonic andothers
|
|
NETWORK |
|
Interface |
1 Gigabit Ethernet (10/100/1000Mbps) |
|
Type |
StaticIP, DynamicIP, xDSL, UPnP,RTSP |
|
DDNS |
WNS, DynDNS, NoIP, WRS |
|
Bandwidth limit |
Supported |
|
NTP |
Server / Client / Both |
|
Users |
10 Monitoring, 2 Playback |
|
Streaming |
H.264 stream, High resolution
1 additional H.264 stream, Normal resolution
1 JPEG stream, Normal resolution for e-mail or mobile |
|
SECURITY |
|
User level |
1 admin, 10 users |
|
User privilege |
Menu, PTZ, Relay, Playback, Power, Copy, Network MIC |
|
IP filtering |
Supported |
|
STORAGE & BACKUP |
|
Storage devices |
2 internal SATA HDDs, 1 external eSATAInterface, Gigabit network for NS04R
|
|
RAID Level |
External storage including NS04R(Level 1/5/10) |
|
File system |
Proprietary file system, Data-loss protection against power-failure |
|
Capacity |
Max. 32TB with eSATA, Max. 128TB with cascaded NS04R
8TB HDD Supported |
|
Backup type |
Multi-channel exe file, Single channel avi file, JPEG(Capture) |
|
Backup device |
USB 2.0 drive (2 ports) |
|
S.M.A.R.T. |
Temperature and Health checking |
|
SERIAL & I/O |
|
Serial port |
1 RS-232C, 2 RS-485 |
|
Sensor input |
16 Dry-contacts |
|
Relay output |
2 Relays |
|
CONTROLLER |
|
Device |
IR remote controller, Joystick Keyboard, Mouse |
|
SOFTWARE |
|
Web viewer |
Plug-in free HTML5 WebViewer |
|
Java viewer |
Monitoring / Event / PTZfor IE, Chrome, Safari,Mac OS X |
|
Mobile viewer |
Monitoring / Playback / Alarm Push / PTZ/ Audio / Log View with iPhone & Android |
|
CMS |
Control Center, Max. 1024 units |
|
SDK |
ActiveX(COM) SDK |
|
ENVIRONMENTAL & PHYSICAL |
|
Dimension |
350(W) × 393(D) × 88(H) mm |
|
Weight |
8 Kg (No HDD) |
|
Operating temperature |
5°C~45°C (41°F ~ 113°F) |
|
Operating humidity |
80% below, free of condensation |
|
Power |
DC 12V/5A |
|
Power consumption |
Max. 50W, Typical 40W(1 HDD) |
|
Approval |
KC, FCC, CE, RoHS |
