One Cable Solution 동축케이블을 통한 카메라 전원공급 및 제어
· PoC(Power over Coax) : 동축케이블을 통해 DVR로 부터 카메라에 전원을 공급하여 별도의 전기공사 불필요
· CoC(Control over Coax) : 동축케이블을 통해 DVR로 부터 카메라 제어신호를 전송하여 별도의 RS485 선로공사 불필요
전용 VMS 무료 지원
최대 1024대의 DVR 연결, 다양하고 막강한 기능으로 효율적인 원격 모니터링이 가능한 전용 VMS(Control Center) 무료 제공
VIDEO INPUT | ||
---|---|---|
Video input format | BNC | HD-SDI (SMPTE 292M), EX-SDI |
D-SUB | Analog 960H/SD | |
IP(Ethernet) | IP Camera(TBD) | |
Resolution / Frame Rate |
HD-SDI EX-SDI |
1920×1080@25, 30fps 1280×720@30, 30, 50, 60fps |
Analog 960H | 960×480@60i | |
Analog SD | 720×480@60i | |
Connectors | 16ch, 75Ω BNC connector | |
PoC | 16ch, Power over Coax, Max. 16W/ch, Total 180W | |
CoC | 16ch, Control over Coax, Max. 57,600bps | |
VIDEO OUTPUT | ||
Video output | HDMI / VGA |
1, 4, 9, 10, 13, 16 split-screen HDMI : 1920×1080 VGA : 1920×1080, 1280×1024, 1024×768, 800×600 User defined display / Alarm pop-up / Sequential switching |
BNC |
1, 4, 9, 10, 13, 16 split-screen CVBS User defined display / Sequential switching |
|
RECORDING | ||
Compression | H.264 / JPEG | |
Resolution | 1920×1080, 1280×720, 960×480 | |
Rate | Max. 480fps | |
Quality | 10 levels up to 8Mbps | |
Mode | Normal/Event, Schedule/Event, Emergency Record | |
Schedule | 24hrs / 7days | |
PLAYBACK | ||
Mode | Instant Playback / Search | |
Speed | Max. 480fps | |
Search type | Date/Time, Calendar/Time-line, Event, Thumbnail(Interval/Motion), Text, Bookmark | |
Block playback | 24hours ~ 99days | |
EVENT & ALARM | ||
Event source | MD(Motion Detection), Sensor, Text, Video Loss | |
Event check schedule | 24hrs / 7days | |
Event action | Relay, Buzzer, E-mail, FTP, Video pop-up, Camera Preset, Mobile Alarm Push | |
MD area | 15×10 | |
Sensor input | Dry contact (NO or NC selectable) | |
Text input | POS/ATM support, AVE VSI Pro/Hydra support | |
SYSTEM ALARM | ||
Alarm source | HDD fail, HDD almost full, Password fail, WRSfail, Fan fail | |
Alarm action | Warning message, Buzzer, E-mail, Relay, Mobile Alarm Push | |
AUDIO | ||
Input/output | 4 RCA input / HDMI & RCA output | |
Compression | ADPCM (32Kbps, 16KHz, 16bit sampling) | |
Direction | Both | |
PTZ | ||
Protocols |
41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Pelco-P, Samsung, Panasonic and others
|
|
NETWORK | ||
Interface | 1 Gigabit Ethernet (10/100/1000Mbps) | |
Type | Static IP, Dynamic IP, xDSL, UPnP, RTSP | |
DDNS | WNS, DynDNS, NoIP, WRS | |
Bandwidth limit | Supported | |
NTP | Server / Client / Both | |
Users | 10 Monitoring, 2 Playback | |
Streaming |
H.264 stream, High resolution 1 additional H.264 stream, Normal resolution 1 JPEG stream, Normal resolution for e-mail or mobile |
|
SECURITY | ||
User level | 1 admin, 10 users | |
User privilege |
Playback, Menu, Copy, PTZ, Camera Setup, Relay, Power, Network Mic
|
|
IP filtering | Supported | |
STORAGE & BACKUP | ||
Storage devices |
5 internal SATA HDDs (12TB equipped as standard),
1 external eSATA Interface, Gigabit network for NS04R
|
|
RAID Level | External storage including NS04R(Level 1/5/10) | |
File system | Proprietary file system, Data-loss protection against power-failure | |
Capacity |
Max. 32TB with eSATA
Max. 128TB with cascaded NS04R
8TB HDD Supported
|
|
Backup type | Multi-channel or Single channel avi file, JPEG(Capture) | |
Backup device | USB 2.0 drive (2 ports) | |
S.M.A.R.T. | Temperature and Health checking | |
SERIAL & I/O | ||
Serial port | 1 RS-232C, 2 RS-485 | |
Sensor input | 16 Dry-contacts | |
Relay output | 4 Relays | |
CONTROLLER | ||
Device | IR remote controller, Joystick Keyboard, Mouse | |
SOFTWARE | ||
Web viewer | Plug-in free HTML5 WebViewer | |
Java viewer | Monitoring / Event / PTZ for IE, Chrome, Safari,Mac OS X | |
Mobile viewer | Monitoring / Playback / Alarm Push / PTZ/ Audio / Log View with iPhone & Android | |
CMS | Control Center, Max. 1024 units | |
SDK | ActiveX(COM) SDK | |
ENVIRONMENTAL & PHYSICAL | ||
Dimension | 445(W) x 418(D) x 88(H) mm | |
Weight | 10 Kg (No HDD) | |
Operating temperature | 5°C~45°C (41°F ~ 113°F) | |
Power | AC free volt (100~240VAC), 50/60Hz | |
PoC Power | DC 24V/7.5A | |
Power consumption | Max. 85W, Typical 45W(1 HDD) | |
Approval | KC, FCC, CE, RoHS |
* 제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
