TDM Time Division Multiplexer
최대 8채널의 비디오를 입력받아 시분할 다중화 하여 한 개의 케이블로 전송하는 방식
TDM(EX-SDI) RX 내장 DVR로 단일 케이블을 통해 최대 8채널 까지 수신 가능
4M QHD 고화질로 더 선명하고 생생하게
고화질의 4M QHD 해상도로 더 넓은 영역의 감시와 원거리 이미지의 확대도 자유롭고 깨끗하게!
Full-HD 보다 2배 더 선명한 4M QHD 해상도의 영상까지 저장 가능한 DVR
전용 VMS 무료 지원
최대 1024대의 DVR 연결, 다양하고 막강한 기능으로 효율적인 원격 모니터링이 가능한 전용 VMS(Control Center) 무료 제공
| VIDEO INPUT | ||
|---|---|---|
| Video input Format | BNC | HD-SDI, EX-SDI(1.0 / 2.x / 3.0) |
| IP(Ethernet) |
WESP, Onvif Profile S H.265, H.265 |
|
| Resolution / Frame Rate | HD-SDI | 1920×1080@30fps,1920×1080@25fps |
|
EX-SDI 1.0 EX-SDI 2.x EX-SDI 3.0 |
1920×1080@30fps,1920×1080@25fps 2560×1440@30fps,2560×1440@25fps |
|
| EX-SDI TDM 1.1 | Not supported | |
| IP |
1st stream: 1280×720~2560×1440 2nd stream: max 1280×720 |
|
| Connectors | 4ch, 75Ω BNC connector | |
| CoC | Control over Coax@HD SDI , EX SDI 1.0 / 2.x / 3.0 | |
| VIDEO OUTPUT | ||
| Video output | Resolution |
HDMI : 3840× 2160, 1920 × 1080 VGA : 1920× 1080, 1280 × 1024, 1024 × 768 |
| Modes | HDMI/VGA Duplicate | |
| BNC(CVBS) | Not supported | |
| RECORDING | ||
| Compression | H.265, H.264, JPEG | |
| Resolution | 1920×1080, 2560×1440 | |
| Rate |
Total 120fps, Max. 30fps/ch @1920 × 1080 Total 120fps, Max. 30fps/ch @2560 × 1440 |
|
| Quality |
10 levels up to (Default - Q7) - H.264 : 4Mbps@2M, 6Mbps@4M - H.265 : 3Mbps@2M, 4Mbps@4M |
|
| IP Camera | Same as BNC Camera | |
| Mode | Normal/Event Record, Schedule/Event Record, Emergency Record | |
| Schedule | 24hrs / 7days | |
| PLAYBACK | ||
| Mode | Instant Playback / Search | |
| Speed |
Total 120fps, Max. 30fps/ch @1920 × 1080 Total 120fps, Max. 30fps/ch @2560 × 1440 |
|
| Search type | Date/Time, Calendar/Time-line, Event, Thumbnail(Interval/Motion), Text, Bookmark | |
| Block playback | 1day ~ 365days | |
| EVENT & ALARM | ||
| Event source | Motion detection, Sensor input, Video Loss, Text input, AI, Flame, Thermal, System | |
| Event check schedule | 24hrs / 7days | |
| Event action | Buzzer, E-mail, FTP, Video pop-up, Camera Preset, Mobile Alarm Push, System alarm | |
| MD area | 15×10 | |
| Text input | POS/ATM support, AVE VSI Pro/Hydra support | |
| SYSTEM ALARM | ||
| Event source | HDD fail. HDD almost full, Password fail, WRS/DDNS fail, Recording Fail, NTP Sync Fail | |
| Event action | Pop-up Message, Buzzer, E-mail, Mobile Alarm Push | |
| AUDIO | ||
| Input/output | HDMI output | |
| Compression | G.711 | |
| Direction | Both | |
| PTZ | ||
| Protocols | 35 models including C1080, C1080PT-Z20, Pelco D, Pelco P, Samsung and Panasonic | |
| NETWORK | ||
| Interface | 1 Fast Ethernet (10/100Mbps) | |
| Type | Static IP, Dynamic IP, xDSL | |
| DDNS | WNS, DynDNS, NoIP, WRS | |
| Tx Bandwidth limit | 1 ~ 77Mbps | |
| NTP | Server / Client / Both | |
| Users | Total 10 Users (Monitor + Playback) Playback 4 Users | |
| RTSP | Supported | |
| UPnP | UPnP auto port forwarding | |
| Streaming |
H.264 stream, H.265 steam High resolution 1 additional H.264 stream, H.265 Normal resolution 1 JPEG stream, normal resolution |
|
| Service streaming | Service Channel or Remote DVR | |
| SECURITY | ||
| User level | 1 admin, 10 users | |
| User privilege | Menu, PTZ, Playback, Power off, Copy, Network MIC, Camera setup | |
| IP filtering | Supported | |
| STORAGE & BACKUP | ||
| Storage devices | 1 internal SATA HDD | |
| RAID Level | Not Supported | |
| File system |
High-performance proprietary file system Safe data protection in power interrupt Safe HDD head parking in power interrupt |
|
| Capacity | 12TB HDD Supported | |
| Backup type | Multi-channel exe file, Single channel avi file, JPEG(Capture) | |
| Backup device |
2 USB 2.0 drive (2 front) FAT32(Max 32GB), NTFS(Max 1TB) | |
| S.M.A.R.T. | Health checking and alarm, Reallocation sector monitoring and alarm | |
| SERIAL & I/O | ||
| Serial port | 1 RS-485 | |
| Sensor input | Sensor of IP camera | |
| CONTROLLER | ||
| Device | Mouse, IR remote controller, Joystick Keyboard (option) | |
| SOFTWARE | ||
| HTML5 Webviewer | Monitoring / Event / PTZ / Playback for browser supporting HTML5 | |
| WebViewer | Monitoring / Event / PTZ / Playback for IE | |
| Mobile viewer | Monitoring / Playback / Alarm Push / PTZ / Audio / Log View with iPhone & Android | |
| CMS | Control Center, Max. 1024 units | |
| SDK | HTML5 SDK, ActiveX(COM) SDK | |
| ENVIRONMENTAL & PHYSICAL | ||
| Dimension | 260(W) × 241(D) × 45(H) mm | |
| Weight | 1.2 Kg (No HDD) | |
| Operating temperature | 5°C~45°C (41°F ~ 113°F) | |
| Operating humidity | 80% below, free of condensation | |
| Power | DC 12V / 3A | |
| IPFR | Supporting IPFR (Intelligent Power Failure Recovery) | |
| Power consumption | Typical 5.4W (w/o HDD) | |
| Approval | KC, FCC, CE | |
REV1.3
( * 표시: 지원 예정 / * Marks: Scheduled to be supported)
제품의 사양은 성능 및 품질 향상을 위해 사전 예고없이 변경 될 수 있습니다.
(Specifications are subject to change without notice for product improvement.)
