One Cable Solution Power supply and Control over One Coax Cable
· PoC(Power over Coax) : Only one Coax Cable is required to supply power. Do not require any power line.
· CoC(Control over Coax) : Only one Coax Cable is required to control camera. Do not require RS485 line.

SONY STARVIS Image Sensor
Highly sensitive SONY STARVIS CMOS Sensor provides crystal clear image in low light condition.
3D-DNR 3D-Digital Noise Reduction
Advanced 3D-DNR technology detects and eliminates unnecessary noise by conducting comprehensive analysis of image pixels.
WDR Wide Dynamic Range
Realize one clear image by combining overexposed and underexposed identical images in backlight condition.
Made in Korea
Different league from low priced Chinese products.
Proven quality of Made in Korea and reasonable price.
|
VIDEO |
|
Description |
NTSC |
PAL |
|
Sensor Type |
2.1Megapixel Sony STARVIS CMOS Sensor |
|
Total Pixels |
1920(H) x 1080(V) = 2.1M pixels |
|
Scanning System |
Progressive Scan |
|
Lens |
Filter |
True Day & Night (ICR) |
|
Type |
2.8~12mm DC IRIS VARIFOCAL LENS (ICR) |
|
Video Output |
Output |
2 BNC 1.0 Vp-p |
|
Resolution |
1080P30 |
1080P25 |
| Format |
1 for TVI or HD-A, 1 for CVBS |
|
Video Control |
Auto Gain Control |
LEVEL 0~10 |
|
S/N Ratio |
More than 52dB |
| BLC |
OFF / HLC / BLC / WDR |
|
ACE |
OFF / LOW / MIDDLE / HIGH |
|
Min. ILLUMINATION |
Color: 0.2Lux@50IRE,F1.3, 3100K, DSS(OFF), AGC(10) / BW: 0.0005Lux@50IRE, F1.3, 3100K, DSS(OFF), AGC(10) |
|
DNR |
OFF / LOW / MIDDLE / HIGH |
|
Iris Adjust. |
DC / MANUAL |
|
White Balance |
AUTO / AUTOext / PRESET / MANUAL |
|
Electric Shutter |
INDOOR / OUTDOOR / INDOOR-ANTI-BLUR /
OUTDOOR-ANTI-BLUR / FLICKER / MANUAL (11 Steps)
|
|
OSD language |
ENG |
|
Day & Night |
COLOR / BW / EXTERN / AUTO |
|
Defog |
OFF / LOW / MIDDLE / HIGH |
|
Privacy |
OFF / ON (Programmable 10 zones) |
|
DSS |
OFF / AUTO / X2~X32 |
|
Digital Effect |
OFF/ H-MIRROR / V-MIRROR |
|
IR LED |
Super IR 18 pcs (range : about 40m) |
|
Smart IR |
OFF / ON |
|
OSD Control |
OSD Key / CoC (UTC) |
|
ELECTRICITY |
|
Power Consumption |
IR OFF : 3W(MAX) / IR ON : 6W(MAX) |
|
Input Voltage |
PoC(DC 33V±10%) |
|
ENVIRONMENTS |
|
Operation Temp. / Humidity |
-10℃~ +50℃/ MAX 90% RH |
|
Storage Temp. / Humidity |
-20℃~ +60℃/ MAX 90% RH |
|
CERTIFICATIONS |
|
Certifications |
Non Certifications |
rev 1.7
( * Marks: Scheduled to be supported )
Specifications are subject to change without notice for product improvement.
