| Video |
| Compression |
H.265(HEVC) main@L5.1,
H.264(AVC) baseline/main/high@L5.2, MJPEG |
| Resolution |
Stream1 : 1920×1080
Stream2 : 1280×720 ~ 640×360
Stream3 : 640×360 ~ 320×184
Stream4 : 1280×720 |
| Bitrate |
100Kbps ~ 10Mbps |
| Bitrate Control |
CBR |
| Frame Rate |
Max. 30fps@1080p |
| GoP |
Max. 120 |
| Streaming |
Stream1 : 1920×1080 30fps
Stream2 : 640×360 ~ 1280×720 30fps
Stream3 : 320×184 ~ 640×360 30fps
Stream4 : 1280×720 (MJPEG) / 5fps |
| Camera |
| Image Sensor |
1/2.8” 2.1Megapixel SONY Starvis CMOS Sensor |
| Max. Resolution |
1920(H) × 1080(V) = 2.1M pi×els |
| Video Output |
Progressive Scan |
| Min. Illumination |
Color |
0.02Lux@F1.3 |
| B/W |
0.0005Lux@50IRE, F1.3, 0Lux(IR LED On) |
| Lens |
Day & Night |
True Day & Night |
| Type |
f=3.6mm Fixed Mega Pixel Lens |
| Angle |
H : 87.24°
V : 47.14°
D :103.66° |
| Features |
Day/Night |
Auto / Color / B&W / Extern / Low Light Color / Scheduled Switch |
| Auto Focus |
Not supported |
| Image Enhancement |
WDR(120dB), BLC, HLC |
| AGC |
Support |
| SNR |
More then 52dB |
| ACE |
Support |
| DNR |
Support |
| DSS |
OFF / x2 / x4 / x8 / x16 / x32 / x64 |
| SHARPNESS |
0~255 |
| Mirror |
Horizontal, Vertical |
| Whitebalance |
Auto / AutoExt / Preset / Manual |
| Shutter |
INDOOR, OUTDOOR, INDOOR-ANTI BLUR, OUTDOOR-ANTI BLUR, MANUAL(1/30~1/30000, 11steps) |
| Privacy Mask |
Support (Max. 8) |
| Event |
Motion, Tampering detection, Smart MD |
| DE-FOG |
Support |
| AI feature |
Intrusion detection, Line crossing, Loitering |
| IR distance |
80m |
| OSD |
Size |
16 ~ 250 pixel |
| Color |
Black, Blue, Green, Red, Yellow, White |
| Position |
Adjustable |
| Input / Output |
| Alarm |
Input |
Not supported |
| Output |
Not supported |
| Video Output |
Output |
Not supported |
| Resolution |
Not supported |
| Audio |
Output |
Not supported |
| Compression |
Not supported |
| System |
| User |
Access rights per account, initialize password, Account Add/Delete/Modify |
| Management |
System log, Time setting |
| Upgrade |
Iptool upgrade, Webpage upgrade, Emergency upgrade |
| Maintenance |
Initialize Settings, Restart, Initialize partial settings,scheduled reboot (*) |
| Webpage Language |
Korean, English, Japanese (*) |
| Network & Software |
| Network & Software |
Ethernet |
RJ-45 (10/100BASE-T) |
| Network Type |
Fixed IP, DHCP |
| DDNS |
WNS(*), WRS(*) |
| Port |
HTTP : 80 / HTTPS : 443 / Onvif : 80 / RTSP : 554 |
| Protocol |
HTTP, HTTPS, RTSP/RTP, TCP/IP, UDP, ARP, ICMP, DHCP, NTP, UPnP (*) |
| IP Camera Protocol |
Onvif Profile S, WESP |
| Simultaneous Live View |
Up to 2 streams with NVR(Onvif/WESP)
Up to 7 streams with WEB
Up to 4 streams with RTSP |
| DST |
Support |
| Web Browser |
Chrome, Edge, Safari, Firefox |
| Web settings |
Desktop (Mac, Linux and Windows) and multi-platform web setup |
| PC CMS Software |
Control Center, Control Center Pro |
| Mobile Viewer |
Support (Android, iOS) |
| Relay Server |
WinRDS |
| Security |
TLS |
Support |
| User Access Logs |
Support |
| IP address filter |
Support |
| Session Close |
Support(*) |
| General |
| Power |
DC 12V /1A, PoE(802.3af) |
| Size |
164(W) ×110(H) ×313(D) mm |
| Power Consumption |
6W
|
| Operation Temperature |
-15°C ~ 60°C(5°F ~ +140°F) |
| Operation Humidity |
0% RH ~ 80% RH |
| Protection |
IP66(*) |
| Certifications |
KC |
| Weight |
990g |
